 (PP-A636) ¾ÆµÎÀÌ³ë ¸Þ°¡ ÇÁ·Î¹Ì´Ï Mega2560 ȣȯº¸µå


ÆǸŰ¡°Ý 20,000 ¿ø(VATÆ÷ÇÔ)
¸ðµ¨¸í PP-A636
Á¦Á¶¿ø Any Vendor [ºê·£µå ¹Ù·Î°¡±â]
Àç°í ÆǸÅÁß
±¸¸Å¼ö·® EA

General information :
1.The Mega Pro Embed CH340G/ATmega2560 board is based on the ATmega2560 microcontroller and USB-UART adapter CH340. This board is compatible with Mega 2560.
2. The board has a small form factor of 38X55mm and is a great solution for developing projects based on the ATmega2560.
3. Mega Pro Embed function is the same as Mega 2560. Despite being an embed board, it is as stable as a mega board. It uses the original chip and a 16 MHz high quality quartz resonator is on the board.
4. The board has a micro USB connector to connect the microcontroller to the computer via USB-UART adapter CH340 (you may need to install the driver). Driver download: Windows, Linux, Mac, Android.
5. The board can be supplied directly through the Micro USB connector or powered through the corresponding contact on the board (Vin). The voltage regulator used works in the 6 to 9V DC range.
6. The maximum output current of 5V is about 800mA, and the output current of 3.3V is about 800mA.
7. The voltage regulator can use up to 18V as the input value, but it is not recommended to exceed the recommended value. Overheating can damage the device.


Specification :
¢º Microcontroller : ATmega2560
¢º USB-TTL converter : CH340
¢º Power Off : 5V-800mA
¢º Power input. : 5V
¢º Power input. VIN/DC jack : 5V
¢º Power consumption : 5V 220mA
¢º Logic level : 5V
¢º USB : Micro usb
¢º Clock frequency : 16MHz
¢º Working supply voltage : 5V
¢º Digital I/O : 54
¢º Analog I/O : 16
¢º Memory size: 256kb
¢º Data RAM type/size : 8Kb
¢º Data ROM type/size : 4Kb
¢º Interface type : ISP
¢º Working temperature : -40¡Æ/+85¡Æ
