 Arduino Mega ADK (R3)

 ¾ÆµÎÀ̳ë ADK ¸Þ°¡ º¸µå´Â USB host controller¿Í Arduino Mega2560À» ÇϳªÀÇ º¸µå¾È¿¡ ³Ö¾î Google ADK¿Í ȣȯµÇµµ·Ï ¸¸µé¾ú½À´Ï´Ù.


ÆǸŰ¡°Ý 93,500 ¿ø(VATÆ÷ÇÔ)
½ÃÁß°¡ 110,000 ¿ø
¸ðµ¨¸í Arduino Mega ADK (R3)
Á¦Á¶¿ø ¾ÆµÎÀ̳ë [ºê·£µå ¹Ù·Î°¡±â]
Àç°í
±¸¸Å¼ö·® EA  Ç°Àý


Arduino ADK Mega º¸µå´Â  USB host controller¿Í Arduino Mega2560À» ÇϳªÀÇ º¸µå¾È¿¡ ³Ö¾î Google ADK¿Í ȣȯµÇµµ·Ï ¸¸µé¾ú½À´Ï´Ù.

À§ º¸µå´Â USB host interface·Î AndroidÆù°ú ¿¬°á ÇÒ ¼ö ÀÖ½À´Ï´Ù. Arduino ÀÇ physical computing ´É·Â¿¡, Android ÆùÀÇ processing power¿Í Åë½Å¿¬°á±â´ÉÀ» °áÇÕÇÏ¿© »õ·Ó°í Àç¹ÌÀÖ´Â project¸¦ ÇÒ ¼ö ÀÖ½À´Ï´Ù. ¿ÜºÎ¿Í »óÈ£ÀÛ¿ëÇÏ°í sensing data ¸¦ Ç¥ÇöÇÏ´Â android ÆùÀ» ¸¸µé¾îº¸¼¼¿ä!

Features

  • ATmega2560 Microcontroller
  • Operating Voltage 5V
  • Input Voltage (recommended) 7-12V
  • Input Voltage (limits) 6-20V
  • Digital I/O Pins 54 (of which 14 provide PWM output)
  • Analog Input Pins 16
  • DC Current per I/O Pin 40 mA
  • DC Current for 3.3V Pin 50 mA
  • Flash Memory 256 KB of which 8 KB used by bootloader
  • SRAM 8 KB
  • EEPROM 4 KB
  • Clock Speed 16 MHz
  • Google ADK Compatable!



Revision 3  new features:

  • 1.0 pinout: added SDA and SCL pins that are near to the AREF pin and two other new pins placed near to the RESET pin, the IOREF that allow the shields to adapt to the voltage provided from the board. In future, shields will be compatible both with the board that use the AVR, which operate with 5V and with the Arduino Due that operate with 3.3V. The second one is a not connected pin, that is reserved for future purposes.
  • Stronger RESET circuit.



Arduino.cc

Google's ADK documentation

Schematic

Pin Mapping
